Eagle 2000F Series - Page 30

- 30 -
6.1 Illustration
Base (continued)
Name
Part Number
Qty
1
Turntable
FG-023F
1
2
Base
FG-7000
1
3
Roller Assembly
FG-013A
12
4
Large Sprocket
FG-008
1
5
Travel Switch Touch Block
FG-009
1
6
Chain Tensioner
FG-012
1
7
Tensioner Sprocket
FG-021
2
8
Travel Switch (turn counter)
TZ-918
1
9
Chain
12A
1
10
Adjustment Screw (main motor)
M10x50
1
11
Cover Plate 1
FG-7002
1
12
Cover Plate 2
FG-7003
1
13
Main Motor Base
FG-005
1
14
Small Sprocket
FG-022
1
15
Motor
CV750-30S
1
16
Tensioner Base
FG-011
1
17
Turntable Slot Cover
FG-023F-A
1
18
Bracket
FG-620F
1
19
Enclosure
FG-3220
1
20
Enclosure Door
FG-3221
1
