Eagle 2000F Series - Page 40

- 40 -
6.7 Illustration
Film Lift & Cutting Assembly – Continued from previous page.
Name
Part Number
Qty
1
Swing Pole
FG-726F
1
2
Swing Pole Fixed Block
FG-725D
1
3
Swing Axis
FG-722F
1
4
Swing Pole Frame
FG-2923B
1
5
Film Picking Cylinder
DGP-18-200-PPV-A-B
1
6
Swing Pole Bracket
FG-620F
1
7
Film Picking Pole
FG-8280
1
8
Film Brush Frame
FG-727F
1
9
Brush Frame
FG-734
1
Insulated Board
FG-733
1
Heating Fuse
3x0.5x500
1
10
Guide Pole
20x30
2
11
Linear Bearing
LM-20UU
2
12
Linear Bearing
001.080.10c
1
13
Film Heating Bracket
FG-8286
1
14
Compression Spring
4
15
Film Heating Bracket
FG-8285
1
16
Idler Wheel Axle
FG-119
1
17
Idler Wheel Bearing
6901
2
18
Roller
FG-115-1
1
19
Film Heating Cylinder
TM-32x30
1
20
Cylinder
SDA-40x70
1
21
Film Lifter Cylinder Bracket
FG-8281
1
