General Usage
5-6
Controls
Ignition Switch (All models without H30)
Your tractor is equipped with either a keyless or keyed ignition switch. Both switches
are three-position switches-OFF, ON and START (Crank).
•
ON POSITION - The fuel pump, electrical system, accessories and fuel-
temperature-voltage gauges are activated. The oil pressure gauge will not fully
activate until the engine is started.
• START POSITION – This is used to start the engine. The engine will crank until
you release the ignition switch. When the ignition switch is released in the start
position, you must turn the switch to the "OFF" position first before returning to
the start position. This is to prevent trying to start the engine when it is already
running (anti-restart protection).
• OFF POSITION - This is used to shut down the engine and turn all electrical
power off (including accessories). Never leave the tractor unattended with the
engine running or the ignition switch in the "ON" position, as this can result in a
run-down battery.
Ignition Switch (4TNV98 Engines)
Your tractor is equipped with either a keyed or no ignition switch. The switch provides
power to the H30 which is used to start the engine. If the case that there is no ignition
switch, the H30 is always connected to a power supply.
Headlight switch
The headlight switch is an on/off type. There is no hi/low beam control position.
Heat Temperature Control (Option)
The heat temperature control is a push/pull control cable and is used to adjust the air
temperature from the heater in a cab. Pull up to set at desired temperature. Push
down to turn heat off.
Heater Fan Control Switch (Option)
The heater fan switch has three positions, OFF, LOW and HIGH.
Windshield Wiper Switch (Option)
The windshield wiper switch (located on the wiper motor) has an on/off position. The
wiper has only one speed.
Defrost Fan Control (Option)
The defrost fan motor has a switch built in. The switch has three positions-OFF, LOW
and HIGH.
