Handling
7-2
Tie Down Procedure
For long distance travel, the TT-series tow tractor can be transported by trailer. When
transporting the tow tractor, please use the following tie-down procedure. This will
ensure that the tractor is securely fastened and will prevent damage to the tractor.
1) Position tractor on trailer, put transmission selector in Park and set Parking Brake.
2) Use correctly sized load chains to secure the tractor to the trailer side tie downs -
Do not use load straps.
3) Run chain though the tie-down rings (if equipped) located behind the E-hitches.
4) Take both ends of the chain out and down away from the tractor and tighten as
required to secure the tractor.
5) Note: chains must not touch front or rear of tractor. Chain contact with the tractor is
with the tie-down rings only.
6) Do not top load anything on the tractor.
7) Do not run straps or chain across the top of the tractor.
