The Fahora P5 E-Bike is an electric bicycle designed for recreational use, offering a blend of power, range, and practical features for urban and outdoor environments. It is important to read the entire manual before assembling and riding the e-bike for the first time. Before unboxing, check for shipping damages and document them with photos. Assistance from a friend is recommended during unboxing to prevent injury or damage to the bike. The serial number, located on the right side of the head tube, should be photographed and backed up as it is required for warranty, insurance, lost & found, and reporting a stolen bike.

Important Technical Specifications:

Model: P5
Battery: 48V 20Ah Removable battery
Charger: 54.6V DC American charger
Motor: 750W
Range: 32 ~ 38 miles with throttle only; 38 ~ 44 miles with pedal assist (with a load of approximately 198lb)
Top Speed: 28 Mph
Tire: 24*4.0 Inch
Brakes: Front and rear hydraulic disc brakes, 180mm rotors
Payload Capacity: 330lb
IP Rating: IPX4
Environment of Use: -10~40°C (14~104°F) indoors and outdoors
Net Weight: 84.8lb
Size: 18507001070mm
Age Required / Recommended Height: 16 years old / 5.4 ~ 6.2ft

Usage Features:

The Fahora P5 E-Bike is equipped with a comprehensive display and control system. The display shows essential information such as battery level, total mileage (ODO), trip mileage (TRIP), maximum speed (MAX), average speed (AVG), current speed, and a "Walk" mode indicator. It also features an error code display and a headlight indicator. The control system includes a head combination switch with a plus button, minus button, power button, info-switch button, and headlight button, along with a throttle and shifter.

Power On/Off: Long press the power button to start working and power the controller. In the boot state, long press the button to turn off the power supply.
Power Gear Adjustment: Short press the plus button to switch the electric vehicle power gear and change the output power of the motor. Press and hold for three seconds to turn on the high beam.
Constant Speed Mode: Long press the minus button to activate a power implementation state where the bike travels at a constant speed of 3km/h. The screen display will also work. Releasing the button immediately returns to the booster state.
Display Information Switch: Short press the info-switch button to toggle between total mileage (km), single mileage (km), maximum speed (km/h), and average speed (km/h).
Headlight Control: Press the headlight button to turn on the near-light lamp and press it again to turn it off.
Automatic Shutdown: In the factory default setting, if the electric vehicle is not used for more than 10 minutes, the instrument will automatically shut down.
Brake Adjustment: The hydraulic brake has a built-in screw to adjust the grip distance.
Shock Absorber: The shock absorber can be locked/activated by twisting a knob. Air shock absorbers cannot be adjusted by twisting the knob.
Riding Posture: Adjust the sitting position, slowly press the accelerator at speed gear, and pedal after balancing.
Gear Shifting: The shifter allows for 1 to 7 gears.
Braking: Release the throttle to slow down. Emergency braking requires a quick press of the brake lever. Warning: Quick braking may lead to insufficient control.
Turning: When turning, lean your center of gravity slightly and slowly turn the handle.
Parking: After cycling, park the bike on a flat road, long press to turn off the power, and drop the foot support to prevent slipping or falling.
Battery Removal: Insert the key into the battery box lock, turn it to the left, move the battery cover in the indicated direction, hold the button marked "PUSH," hold the battery box handle, and pull the battery outward.
Charging: The e-bike offers two charging methods: whole vehicle charging and external charging.
- Whole Vehicle Charging: Find the charging port above the rear shock absorber, open the rubber plug, connect the output end of the charger, then connect the power supply. Fasten the rubber plug after charging.
- External Charging: Take out the battery, open the rubber plug of the charging port, connect the output end of the charger to the charging port of the body, then turn on the power supply. Fasten the rubber plug after charging.
- Charging Precautions: Charge with the power off using the original charger. Do not charge if the charging port, power socket, or charging line is wet, or if the vehicle is flooded. Stop charging immediately if the indicator light is abnormal or if there is an abnormal smell. Keep the charger away from inflammables and explosives and out of reach of children. Disconnect power immediately after charging and do not leave the charger connected to the power supply for long periods when not charging. Regularly check the charger wire, plug, shell, and other parts for damage.

Maintenance Features:

Regular maintenance is crucial for the longevity and safe operation of the Fahora P5 E-Bike.

Cleaning: Wipe the main frame with a soft damp cloth. For stubborn stains, use a professional cleaner. Do not use alcohol, gasoline, kerosene, or other corrosive/volatile solvents. Do not use pressure water guns or hose sprays for flushing. During cleaning, ensure the e-bike is turned off, the charging cable is unplugged, and the rubber cover of the charging port is fastened to prevent electric shock or internal water damage.
Storage: Store the e-bike in a dry and cool place indoors, avoiding prolonged outdoor storage. Sun exposure, hot/cold outdoor conditions accelerate aging of appearance, tires, and reduce battery pack service life. Fully charge the electric bicycle before storing, and if not used for a long time, charge it regularly to prevent battery discharge. Do not store in dusty environments or with chemicals, acids, or alkalis. Keep away from fire sources.
Battery Maintenance: A fully charged battery will use up its stored power in 120-180 days when turned off. If not used for a long time, charge it every 30-60 days. Charge the battery after each drive. A completely depleted battery may cause permanent damage. Damage due to overcharging or undercharging is not covered under warranty. Do not remove or disassemble the battery, use other types/brands of battery packs, touch battery contacts, open or puncture the case, or throw the battery pack into fire. Dispose of used batteries properly through professional departments.
Charger Maintenance: Use chargers exclusively for vehicles. Confirm connected power is 110V-220V AC. Do not use damaged lines or loose connectors. Charge in a safe place, away from rain and sun exposure. Insert the vehicle's charging port first, then the charger's power plug.
Brake Cable Adjustment: If the brake cable is loose or not sensitive, the brake cable screw can be adjusted.
Tire Repair: Tire repairs should be performed by professional service personnel.
Self-Maintenance Schedule:
- First maintenance: 1000 km or 3 months after delivery (whichever comes first).
- Subsequent maintenance: Every 2000 km or 6 months (whichever comes first).
- Specific Maintenance Items:
  - Adjust or replace front and rear brakes: A (Adjust) or A/R (Adjust/Replace) at 3, 9, 15, 21, 27, 33 months / 1000, 3000, 5000, 7000, 9000, 9000 km.
  - Check handlebar steering: C (Check) at all intervals.
  - Check tire pressure: C (Check) at all intervals.
  - Check disc brake system: C (Check) at all intervals.
  - Tighten main component: T (Tighten) at all intervals.
  - Lubrication of main parts: L (Lubricate) at all intervals.
  - Front and rear suspension adjustment: A (Adjust) at all intervals.
  - Check light system: C (Check) at all intervals.

Warranty Service:

The warranty covers various parts of the e-bike for specific periods:

Electronic Control Unit:
- Motor: 12 Months (Quality fault/breakdown/performance failure)
- Battery: 12 Months (Quality fault/power capacity tested lower than 50% of rated capacity)
- Controller: 6 Months (Performance failure)
- Charger: 3 Months (Performance failure)
- Sensor: 3 Months (Performance failure)
- Display/Dashboard: 3 Months (Performance failure)
Mechanical Parts:
- Frame: 24 Months (Desoldering/material fracture)
- Fork: 12 Months (Performance failure)
- Tires: 3 Months (Crack/leaking)
- Saddle: 3 Months (Crack/damaged)
- Other Parts: 3 Months (Damaged/performance)
- Front/Middle axle: 3 Months (Performance failure)

Warranty Notes:

If the motor breaks down after being replaced once within the warranty period, charges for replacement and freight will apply.
The battery housing is not covered under warranty.

Non-Warranty Provisions:

The warranty does not cover: unauthorized maintenance, misuse, collision, negligence, abuse, liquid entry, accident, changes, incorrect use of accessories, or torn/changed/anti-counterfeit labels; expired warranty period; damage caused by force majeure; failure to meet performance error conditions; failure to use, maintain, and adjust according to the manual; damage caused by human factors (punctured tires, collisions, marks, normal wear of delicate parts); failure and damage caused by abnormal use (overload, stepping down, falling, extreme sports); or if the product is used for commercial purposes.

Frame Code & Motor Code:

Motor Numbering Rules: The number is engraved on the end cover of the motor.
- Example: 26 4 11E 48 750 1904 - 00001
- 26: Wheel diameter (26 inches)
- 11E: Chuanke motor model (RW11E motor)
- 48: Voltage level (DC48V)
- 750: Motor power (750W)
- 00001: Production serial number (from 00000 to 99999)
Frame Number: Located in the head tube position.
- Example: P5 2023 666666
- P5: Product model
- 2023: Production year (2023)
- 666666: Production serial number (from 000000 to 909999)

Safety Instructions:

Always wear a helmet and full protective gear (knee pads, wrist pads, elbow pads, sports shoes, suitable clothing). Long hair or bangs affecting sight should be tied up.
Obey local traffic regulations and do not ride in prohibited areas or on public transport roads. Avoid roads infested with motorbikes.
Be aware of the risk of injury or death from loss of control, collisions, and falls. Read and follow all "cautions" and "warnings."
Assembly and adjustment must be done by the rider's guardian or another adult. Not for people under 16 years of age.
Keep packaging materials (wrenches, plastic bags) away from minors.
Do not lend the e-bike to someone who cannot operate it. Ensure new riders are aware of proper usage and safety.
Riding Environment and Pavement: Avoid steep slopes, bumpy roads, slippery roads, pits, sewage openings, stairs, snow, water edges, furnaces, flower beds, expansion joints, construction roads, debris, and other obstacles. Observe traffic and maintain a slow cycling speed. Do not ride in snowy, rainy, muddy, or icy conditions to prevent loss of balance or grip. Water intake due to rain is not covered by warranty.
Do not ride in bad weather or poor visibility (e.g., at night).
Riding Precautions: Only one person is allowed; overloading is strictly prohibited. Grip handlebars with both hands; do not hang ornaments or heavy objects. Do not speed up or slow down suddenly. Do not go faster than the e-bike limit. Avoid putting hands and feet into the rolling wheel. Pay attention to road conditions and avoid obstacles.
If the electric bike makes abnormal or alarm sounds, stop using it immediately.
Rider Requirements: Not suitable for persons under the influence of alcohol or drugs, those unable to perform strenuous physical activity due to medical conditions (heart, neck, back problems), those who cannot keep their balance, those whose age/height/weight are outside prescribed limits, or those with limited intelligence unable to understand proper use and risks.
Operation Notice: Use only parts and accessories designated or approved by the company. Do not modify the electric bike. Do not drive when ambient temperature exceeds operating limits (-10~40°C) as it affects power and performance. Do not let minors touch fenders, wheels, or other structures with gaps. Avoid touching brakes or hub motor after riding due to elevated temperature. Park on flat, firm ground, preferably near a wall. Avoid busy areas. If parking on a slope, orient the kickstand downhill. Ensure stability to prevent falling.
Regular maintenance is recommended. Read charging steps and precautions.
Do not park in safety exits, evacuation passages, or prohibited parking areas. Do not throw, drop, or place the product on open flame or under high temperature.
Use the original battery pack and charger.
Connect power cable to correct socket (100V-240V to 50Hz/60Hz), keep away from children, pets, and flammable objects. Do not use damaged or flooded batteries. Do not charge if the socket is wet.
Do not immerse battery or vehicle body in water or expose to heavy rain.
Battery power will be consumed over time due to intelligent and alarm systems. Store battery separately and maintain regularly if not used for a long time.
Do not store battery in environments higher than 50°C or lower than -20°C.
Do not store battery or vehicle in a place with a risk of falling.
Do not destroy the battery. If it has a peculiar smell, heat, deformation, or other abnormal conditions, stop using it and contact after-sales.
Damage due to user's failure to use and maintain the battery normally is not covered by the three guarantees.
Dispose of used batteries properly.
Avoid non-original parts; do not disassemble, crack, or modify the product without authorization.

The Fahora P5 E-Bike is a robust and feature-rich electric bicycle designed for a safe and enjoyable riding experience, provided the user adheres to the detailed instructions and maintenance guidelines outlined in the manual.
