COMPONENT MAINTENANCE
MANUAL
UXF-35 LIFE PRESERVER, Part No. P01202-1XX
Page 5
Feb 12/16
25-60-35
2. B. Certification
The Model UXF-35 life preserver assembly is manufactured and approved for
certification in compliance with the Federal Aviation Administration (FAA)
requirements for Technical Standard Order (TSO) C13f.
NOTE: TSO compliance regarding the installation and use of the UXF-35 life
preserver assembly aboard the aircraft is the responsibility of the aircraft
operator.
NOTE: The conditions and test required for TSO approval of the UXF-35 life
preserver are minimum performance standards. It is the responsibility of
those desiring to install the UXF-35 either on or within a specific type or
class of aircraft to determine that the aircraft installation conditions are
within the TSO standards, the UXF-35 may be installed only if further
evaluation by the applicant documents an acceptable installation and is
approved by the Administrator.
TOP
MODEL UXF-35 FAA-TSO-C13f
FOR WEARERS WEIGHING 35 LBS. (15.9 KG.) AND ABOVE.
LIFE PRESERVER & CONTAINER ASSY. P/N P01202-"A"
INCLUDES INFLATABLE LIFE VEST ASSY. P/N P01203-"B"
MFD. BY: EA STERN AERO MARINE MIAMI, FLOR IDA U.S.A.
USE EAM 33 GRAM CO CYLINDER P/N 509-06.
SERVICE PER CURRENT REVISION OF EAM CMM 25-60-"C"
2
INSP.
EASA-ETSO-C13f
TOP
MODEL UXF-35
FAA-TSO-C13f
FOR W EARE RS W EIGH ING 3 5 LBS . (15.9 KG.) AND ABOVE. LIFE P RESE RVER & CO NTAI NER A SSY. P/N P01202-"A" INCLU DES IN FLATA BLE LIFE VEST AS SY. P/N P01203-"B" MFD. BY: EA STE RN AERO MARINE MIAM I, FLO RIDA U.S.A.
USE E AM 33 GRAM CO CYLINDER P/N 509-06.
SERVICE PER CU RRENT REVISION OF EAM CMM 25-60-"C"
2
INSP.
EASA-ETSO-C13f
UXF-35 OUTLINE DIMENSIONS
FIGURE 4
