EAM UXF-35 - Leading Particulars; Specifications

COMPONENT MAINTENANCE
MANUAL
UXF-35 LIFE PRESERVER, Part No. P01202-1XX
Page 4
May 14/12
25-60-35
2. LEADING PARTICULARS
A. General
An overall table of specifications for the UXF-35 Series Life Preserver is shown
below in Figure 3.
SPECIFICATIONS
Inflated Buoyancy 35 lbs. (150 Newtons) minimum
Inflated volume 970 cu. in. (16 liters) minimum
Approvals
USA FAA TSO-C13f
EASA ETSO-C13f
Category of Preserver Adult/Child Combination
Weight of wearer 35 lbs. (15.91kg) and above
Dimensions
Inflated
21 x 16 x 6 inches, typical
(53.34 x 42.4 x 15.24 cm)
Deflated and unpacked See Figure 4
Packed See Figure 4
Weight See Figure 2
Inflatable Buoyancy Cells
Material
Construction
1 Cell
Urethane Coated nylon
RF Heat Sealed Seams
Color See Figure 2
Environmental
Temperature
Functional Range: -40 to 140
o
F (-40 to 60
o
C)
Storage Range: 0 to 120
o
F (-17.8 to 48.9
o
C)
Humidity
Functional Range: Up to 95% Relative Humidity
Storage Range: Up to 70% Relative Humidity
Altitude -2000 to 45,100 feet above sea level
CO
2
Gas Charge 1 x 0.073 lb. (1 x 33 g)
Service Life
Indefinite if unit continues to pass periodic
maintenance inspection.
Frequency of Inspection See Testing and Fault Isolation
MODEL UXF-35 LIFE PRESERVER SPECIFICATIONS
FIGURE 3
