Ear Force STEALTH 520 - PS4 Setup

10
Go to Table of Contents
PS4
™
Setup
The Ear Force
®
STEALTH 520 headset is designed for use with PS4™ consoles.
1. Plug the Removable Mic Boom into the jack on the left earcup of the Headset.
2. Connect the square optical plug of the Digital Optical Cable to the Digital Out (Optical) port of
the PS4
™
console.
3. Insert the small plug of the Digital Optical Cable into the Digital Optical Input on the side of the
Wireless Transmitter.
4. Insert the Wireless Transmitter into a USB port on the PS4
™
console.
