Operator's Manual
MC25 2-Cycle Cultivator
Check for parts online at www.getearthquake.com or call 800-345-6007 M-F 8-5
17
ILLUSTRATED PARTS BREAKDOWN
ITEM
NO.
PART
NO.
DESCRIPTION QT Y.
1 26119 AIR FILTER COVER 1
2 26116 FOAM AIR FILTER ELEMENT 1
3 26114 ELEMENT REINFORCEMENT
PLATE
1
4 26209 BOLT M5 X 0.8 X 55 MM 2
5 26075 KIT AIR FILTER HOUSING 1
6 27127 KIT CARBURETOR 1
7 26110 GASKET CARBURETOR 1
8 26208 BOLT M5 X 0.8 X 25 MM 2
9 26108 WINDPIPE CARBURETOR 1
10 26107 GASKET WINDPIPE 1
11 27128 KIT ENGINE SHROUD 1
12 26103 GROMMET ENGINE SHROUD 1
13 26104 CAP ENGINE SHROUD 1
14 26213 SPACER FIBER 5.5 X 12.5 X 4 MM 1
15 26207 BOLT M5 X 0.8 X 20 MM 3
16 26202 BOLT M4 X 0.7 X 12 MM 1
17 26095 RECOIL ASSEMBLY 1
18 26203 BOLT M4 X 0.7 X 16 MM 4
19 26098 CUP RECOIL CLUTCH 1
20 26210 BOLT M5 X 0.8 X 55 MM BLK OX 2
21 26129 CAP MUFFLER 1
22 27129 KIT MUFFLER 1
23 26105 GASKET MUFFLER MOUNT 1
ITEM
NO.
PART
NO.
DESCRIPTION QT Y.
24 26130 GASKET MUFFLER 1
25 26215 PAD FUEL TANK MOUNT 2
26 26120 BRACKET FUEL TANK MOUNT 1
27 26121 BOOT FUEL TANK MOUNT 1
28 26227 BOLT M5 X 0.8 X 16 MM 14 OD 2
29 27130 KIT FUEL TANK 1
30 26128 FUEL TANK CAP SELF VENTING 1
31 27131 KIT FUEL LINES 1
32 26122 FUEL FILTER 1
33 26102 SPARK PLUG TORCH L8RTC 1
34 27132 KIT IGNITION COIL 1
35 26097 FLYWHEEL 1
36 400024 WASHER M8 X 16 X 1.6 MM 1
37 21640 WASHER M8 SPRING LOCK 1
38 3252 NUT M8 X 1.25 HEX 1
39 26211 WASHER M6 X 15 X 1.1 BLK OX 2
40 27133 KIT CLUTCH ROTOR 1
41 25177 WASHER WAVE M8 2
42 25178 BOLT M6 X 1.0 X 21.75 MM 2
43 26212 STUD 4 X 10 X H8 MM 2
44 26100 FLYWHEEL SHROUD 1
45 26205 BOLT M5 X 0.8 X 16 MM 4
Engine Assembly
