EarthQuake MC43 User Manual

Operator's Manual
MC43 Series Mini-Cultivator
Check for parts online at www.getearthquake.com or call 800-345-6007 M-F 8-5 25
ENGINE PARTS LIST
KEY
NO. PART NO. DESCRIPTION QT Y.
1 300484 FLYWHEEL, MAGNETO 1
2 300337 NUT, FLANGE M8 1
3 300462 WASHER, ROTOR 2
4 300413 CLUTCH ROTOR ASSEMBLY W/SPRING 1
5 300449 WASHER, SPRING 2
6 300450 BOLT, SHOULDER 2
7 300467 PIN, LOCATING 2
8 300487 MOUNT RING & SHROUD 1
9 300491 RECOIL CLUTCH 1
10 300429 PLATE, RECOIL 1
11 3004121 HANDLE, RECOIL STANDARD 1
12 300430 RECOIL ASSEMBLY WITH STANDARD
HANDLE
1
13 300472 IGNITION COIL, MC43 1
300472CE IGNITION COIL, MC43 CE 1
300191 IGNITION COIL, MC43E 1
300191CE IGNITION COIL, MC43E CE 1
14 300482 SHROUD, ENGINE 1
15 300493 BOLT, STUD M6 X 62MM 2
16 300475 GASKET, MUFFLER 1
17 4813 MUFFLER 1
18 4812 COVER, MUFFLER 1
19 BM6A SPARK PLUG 1
20 300483 COVER, ENGINE SHROUD 1
21 300476 GASKET, INTAKE 1
22 300478 WINDPIPE, INTAKE 43CC/51CC 1
23 300479 GASKET, CARBURETOR 1
24 300486 CARBURETOR 1
25 300481 ORING, CARBURETOR 1
26 3004109 PRIMER BULB 1
27 3004158 COVER, AIR FILTER 1
28 3004150* AIR FILTER ASSEMBLY 1
29 3004156 FOAM, AIR FILTER 1
30 3004157 PLATE, REINFORCEMENT 1
KEY
NO. PART NO. DESCRIPTION QT Y.
31* 3004150 AIR FILTER ASSEMBLY 1
32* 3004150 AIR FILTER ASSEMBLY 2
33* 3004150 AIR FILTER ASSEMBLY 1
34* 3004150 AIR FILTER ASSEMBLY 1
35* 3004150 AIR FILTER ASSEMBLY 1
36 56105 BRACKET, GAS TANK 1
37
(a)
3004118 GAS TANK KIT 1
38 300401 GAS CAP, MANUAL VENTING 1
39 300332 SHROUD, GAS TANK 1
40 1021 SWITCH, ROCKER 1
-- 1021CE ON/OFF SWITCH WIRE ASSEMBLY REMOTE
HANDLEBAR (Not Shown-For CE Models Only)
1
41
(b)
3004105 KIT FUEL LINE TWO HOLE GROMMET 1
42
(b)
3004105 KIT FUEL LINE TWO HOLE GROMMET 1
43
(b)
3004105 KIT FUEL LINE TWO HOLE GROMMET 1
44 300335 BOLT W/WASHER PHILLIPS HH 4
45 300492 NUT, FLANGE M6 2
46 300471 BOLT W/WASHER M5 X 12MM 4
47 300439 BOLT W/WASHER PH M5 X 18MM 7
48 300336 BOLT HH M6 X 10MM 2
49 300438 BOLT W/WASHER M5 X 25MM 2
50 300456 BOLT M5 X 50MM 2
51 300338 KEY, FLYWHEEL 1
52 3004103 FILTER, FUEL 1
53 300351 BOLT HH M6 X 8MM 2
61 300326 GUARD
- 3004114 KIT, CARBURETOR 1
-- KITTU101 KIT, TUNE UP 1
MC43E ELECTRIC START MODEL ONLY
54 300525 STUD BOLT M6 X 41MM 1
55 300339 KEY, ELECTRIC STARTER 1
56 300527 STARTER WIRE 1
57 300529 STARTER MOTOR KIT (includes starter,
stud bolt, clutch drum & ground wire)
1
58 300445 WASHER M5 2
59 300438 BOLT W/WASHER M5 X 25MM 2
60 300439 BOLT W/WASHER PH M5 X 18MM 2
*Air lter assembly includes: air lter base (28), choke lever bolt (31),
two choke lever washers (32), nylock choke lever nut (33), choke lever
(34) and choke paddle (35)
(a) Gas tank kit includes: gas tank (37), gas cap (38), two-hole grom-
met (41), fuel line and fuel lter (43, 52).
(b) These parts are available as part of fuel line repair kit. Fuel line
repair kits includes: two-hole grommet (41), fuel line hose (42), primer
line hose (43) and fuel lter (52)

EarthQuake MC43 Specifications

General

Engine Displacement	43cc
Tilling Depth	up to 8 inches
Tilling Width	6 to 10 inches
Fuel Capacity	0.21 gal (0.8 L)
Warranty	5-Year Limited
Engine Type	4-Cycle OHV
