EarthQuake MC43 User Manual

Operator's Manual
MC43 Series Mini-Cultivator
Check for parts online at www.getearthquake.com or call 800-345-6007 M-F 8-526
The Border-Edger Kit is a useful tool for making clean cuts in
the lawn along the borders of gardens, ower beds, walkways,
and driveways for a well manicured look. To install the Border-
Edger Kit, do the following:
1. Disconnect spark plug wire from spark plug.
2. Remove the cotter pins from both sides of the tine shaft.
3. Remove the cultivating tines from the shaft, remembering
which direction they are facing.
4. Put the tines in a safe place and save the (2) cotter pins, they
will be used on the Border-Edger Kit.
5. Slide the Border-Edger attachment on either side of the
tine shaft. Make sure that the hub collar of the border edger
tine faces outward, away from the transmission of the mini-
cultivator.
6. Put (1) cotter pin, at side facing edger attachment, through
the shaft hole that is further down the shaft from the hole
where the cultivating tines were placed.
7. Slide the wheel on the opposite tine shaft.
8. Insert the remaining cotter pin, at side facing wheel, through
the hole next to the wheel at the end of the tine shaft.
9. Re-connect spark plug wire.
10. Before using the Border-Edger Kit, remove the drag stake from
the unit.
11. Set the mini-cultivator wheels to their highest (top) position.
EK43 Border-Edger Attachment Kit (ts both Models MC43 & MC43E)
CAUTION
BE AWARE THAT THE MINICULTIVATOR COULD UNEX
PECTEDLY BOUNCE UPWARD, OR JUMP FORWARD IF
THE TINES STRIKE CONCRETE, PAVEMENT, OR OTHER
HARD SURFACES OR HARD OBSTACLES BURIED UN
DER GROUND.
EK43 BORDEREDGER KIT INSTALLATION OPTIONAL ACCESSORY
Revised 4.16.08
46134
cotter pin
46131
wheel
4651
tine shaft
46134
cotter pin
46130
border-edger tine

EarthQuake MC43 Specifications

General

Engine Displacement	43cc
Tilling Depth	up to 8 inches
Tilling Width	6 to 10 inches
Fuel Capacity	0.21 gal (0.8 L)
Warranty	5-Year Limited
Engine Type	4-Cycle OHV
