PRODUCT SPECIFICATIONS
Model: SN71022
Power supply voltage: 120V-60HZ Clearing width: 22 inches (560 mm)
Idle speed: 2200 RPM Max clearing depth: 12 inches (305 mm)
Power consumption: 14 Amp Clearing capacity: 800 pounds/minute
Weight: 31 pounds Throwing distance: Up to 30 feet
5
Model SN71022
PARTS LIST
7 Knob
8 Cable retainer
No. Description
9 Center handle
10 Cotter Pin
11 Auxiliary handle
12 Lower handle
13 Wheel assy.
14 Scraper blade
15 Auger
16 Side cover
17 Discharge chute
18 Chute deflector
No. Description
1 Upper handle
2 Bail wire
3 Switch button
4 Cable clip
5 Crank handle
5A Upper crank
5B Lower crank
6 J bolt
