Easee Charge Lite - Backplate Preparation Steps; Sealing Plug Adjustment; Cable Entry and Strain Relief

10
Backplate
Preparing
4
Shorten the sealing plug to fit the cable. The hole
should be slightly smaller than the cable to ensure
a good seal.
Insert the cable through one of the 4 cable entries
and secure it to the backplate with the strain relief
provided.
Close all cable entries that are not in use with the
supplied blind plugs.
1
2
3
1 2
3
33
1
x 1
2
x 2
3
x 3
