WARNING
Always work with the power off and in
accordance with local regulations. Use
extreme caution and follow instructions
carefully.
Installation
instructions
Bend down the lower part of the rubber cover and
insert the two ends of the front cover tool into the
two openings at the bottom of the front cover.
Pull the tool until the front cover comes loose and
remove the cover.
Grasp the Type 2 socket and push upwards with
good force until the Chargeberry disconnects. Make
sure you do not touch the cable locking mechanism.
1
2
3
1
1
2
2
3
Opening
Charging Robot
