Technical specifications
General
Type designation Easee AC Charger Platform CB-A3-2
Dimensions 256 x 193 x 106 mm (H x W x D)
Drilling hole distance c/c 160 x 125 mm (H x W)
Operating temperature -30 °C to +40 °C (indoor and outdoor use)
Weight 1.5 kg
Sensors and indicators
Light strip with LEDs showing the status of the charger
Touch button
Temperature sensors in all main contacts
Chargeberry technical specifications
Max charging power capacity IT 3 phase: 3x 27 A = 6.37 kW
TN 3 phase: 3x 16 A = 11 kW
IT/TN 1 phase: 1x 32 A = 7,2 kW
Connection point Type 2 socket (IEC 62196-2)
Number of phases 1 or 3 (fully dynamic)
Voltage 3x 230/400V AC (±10%)
Mains frequency 50 Hz
Built-in energy meter (±2 %)
Backplate technical specifications
Max charging power capacity 1.4–22 kW
6 A 1 phase – 32 A 3 phase
Up to 7.36 kW at 32 A 1 phase
Up to 22 kW at 32 A 3 phase
Voltage 3x 230/400V AC (±10%)
Mains frequency 50 Hz
