TERRIER SERIES SWING GATE OPENER USER MANUAL
6
1.3 TECHNICAL FEATURES :
TERRIER150 TERRIER200
Low Voltage
24V
24V power supply
for great safety
Durability
Solid material apply
with lasting usage
EZ Instal
Easy installation
and user friendly
interface
Silence
Worm gear application
give silence operation
Manual release device
with easy use and
highly protection
Key Release
1.4 MAINTENANCE:
Conduct the following operations at least every 6 months. If in high intensity of use,
shorten the period in between.
Disconnect the power supply:
(1) Clean and lubricate the screws, the pins, and the hinge with grease.
(2) Check the fastening points are properly tightened.
(3) Make the wire connection are in good condition.
Connect the power supply:
(1) Check the power adjustments.
(2) Check the function of the manual release.
(3) Check the function of photocells or other safety devise.
Motor
Gear type
Thrust
Stroke length
Power supply
Maximum operating
Maximum gate weight
Maximum gate length
Duty cycle
Operating Temperature
Dimension
Weight
24Vdc motor with mechanical release
Worm gear
1500N
360mm
24Vdc
4.2A for maximum 10 seconds.
150 kg per leaf
2 meters
20%
-20
o
C~+50
o
C
694mm * 100mm * 197mm
3.1kg
24Vdc motor with mechanical release
Worm gear
2000N
400mm
24Vdc
4.2A for maximum 10 seconds.
200 kg per leaf
2.5 meters
20%
-20
o
C~+50
o
C
819mm * 100mm * 197mm
3.6kg
