A
STANDARD INSTALLATION
TERRIER SERIES SWING GATE OPENER USER MANUAL
2
1.2 STANDARD INSTALLATION
1. 24V DC Flashing Light
2. Push Button
3. Control Box
4. Photo Sensor
5. 24V DC gate opener
6. Transmitter
2x1.5 mm
2
2x1.5 mm
2
4x0.5 mm
2
TX - 4x0.5 mm
2
RX - 4x0.5 mm
2
3x1.5 mm
2
2x1.5 mm
2
2x1.5 mm
2
6
2
3
1
DIMENSIONS OF MOTOR:
TERRIER150
TERRIER200
B
5
5
4 4
