go further, and press the filament with a little force to keep it.
●Then use another hand to shift the gear (at the side
of printer control box base)to” FEED "gear(As shown
in the figure ), the light of the print button will
blinking.
●Blinking fast indicates that the nozzle is heating up.
When the temperature reaches, the light turns to
blinking slow, And the motor gear starts to turn and
roll the filament into the nozzle. The whole process
needs to be pressed by hand to ensure that the
filament can be caught and rolled in by the gear.
When the filament come out from the nozzle, it
means that the feeding is successful. The whole
feeding process takes about 1 minute, Please be
patient and wait.
●After feed succeed, you must shift the gear back to
the middle PRINT POSITION.
Feeding failure reason normally :
(1) The front end of the filament is not straight;
(2) Didn’t keep pressing the filament with a little force during the whole process.
（3）Print
Insert the TF card with gcode file (the direction of the TF card should be correct as shown in the
figure below), press the print button , and the light on the print button will start flashing after
the printer reads the gcode file, and the nozzle will start heating. Please wait patiently for
about one minute. When the temperature reaches, the printer will start printing. (Note: The
printer only prints the latest gcode. The gcode file name can only use English letters or numbers.)
There is a gcode test file in the TF card, which is directly printed for the first time.
Don't press the print button repeatedly!!!
（4）Pause/Restore
during printing, Click ,the button light stops flashing , then printing paused.
If need to continue print , Click to restore, the button light flashes again , the printer goes back
to print .
