200 A 15/25 kV class elbow installation instructions
InstallatIon InstructIons MN650042EN February 2017
8
1
/
2
"
(216 mm)
Bend
neutral
wires down
and out of
the way
Insulation
shield
1
15
/
16
"
(49.2 mm)
Conductor
1
/
8
" Bevel
Wire
brush
conductor
Jacket
seal
Step 1 Step 2 Step 3 Step 4
5
3
/
4
"
(145 mm)
Insulation
Installation instructions
Cable stripping and scoring tools, available from various tool
manufacturers, are recommended for use when installing
deadbreak elbows. After preparing the cable, the elbow
housing is pushed onto the cable. The probe contact is
threaded into the coppertop connector using the supplied
installation tool or an approved equivalent. Use a hotstick to
perform installation and removal operations.
Complete elbow kit includes:
• Elbow Body with Test Point
• Coppertop Compression Connector
• Probe Contact
• Probe Installation Tool
• Bail Assembly
• Silicone Lubricant
• Instruction Sheet
Tools/Accessories needed:
• Tape Measure
• Wire Brush
• Knife
• Cable Stripping Tool
• Crimping Tool
• Cable Cleaner
• Cable Cutters
• Emery Cloth
