Eaton 5P 650i - Installation of Rack Models (650 I R Only); Installation of Rack Models (850 I R; 1150 I R; 1550 I R)

Page 14
620-00082-02-i (en)
3.5 Installation of rack models (850i R / 1150i R / 1550i R)
Follow steps 1 to 4 for module mounting on the rails.
3. Installation
1
1
2
2
3
3
4
4
The rails and necessary hardware are supplied by EATON.
3.4 Installation of rack models (650i R only)
Follow steps 1 to 3 for rack mounting.
2
3
2
3
1
