Read This Manual First
Read and understand the contents of this manual and follow
all locally approved procedures and safety practices before
installing or operating this equipment.
Additional Information
These instructions cannot cover all details or variations
in the equipment, procedures, or process described nor
provide directions for meeting every possible contingency
during installation, operation, or maintenance. For additional
information, contact your Eaton representative.
Acceptance and Initial Inspection
Each PUSH-OP bushing adapter cap is in good condition
when accepted by the carrier for shipment. Upon receipt,
inspect the shipping container for signs of damage. Unpack
the PUSH-OP bushing adapter cap and inspect it thoroughly
for damage incurred during shipment. If damage is
discovered, file a claim with the carrier immediately.
Handling and Storage
Be careful during handling and storage of the PUSH-OP
bushing adapter cap to minimize the possibility of damage.
If the PUSH-OP bushing adapter cap is to be stored for
any length of time prior to installation, provide a clean, dry
storage area.
Standards
ISO 9001 Certified Quality Management System
Installation instructions
PUSH-OP bushing adapter cap kit
•
Each kit contains:
• Bushing Adapter
• Silicone Lubricant
• Installation Instructions
• 200 A Loadbreak Protective Cap (Optional)
Equipment required
•
Tools:
• Torque Wrench (Catalog Number 15/25 kV - TQHD625,
35 kV - TQHD635)
• T-Wrench (Catalog Number T-WRENCH)
• O & T Tool (Catalog Number 15 kV - OT615, 25 kV -
OT625, 35 kV - OT635)
• Combined O & T/Torque Tool (Catalog Number 15 kV -
OTTQ615, 25 kV - OTTQ625, 35 kV - OTTQ635)
ote:N If Combined O & T Tool is used, a separate O & T tool
and torque wrench is not required.
Step 1.
Clean and lubricate
•
Clean and lubricate 600 A and 200 A interfaces of
PUSH-OP bushing adapter cap with lubricant supplied or
approved equivalent.
•
Clean and lubricate mating surface of PUSH-OP bushing.
Step 2.
Ground
•
Attach drain wire to system ground bus.
