Step 3.
Assemble to apparatus bushing
Grasp operating eye on bushing adapter with hotstick and
pull eye completely into hotstick.
Place bushing adapter cap on PUSH-OP apparatus
bushing, engaging shroud pins in bail bracket locking
slots, and push until latch plate engages first notches.
Release operating eye from hotstick.
Push forward on push plate until a bump is felt and latch
plate engages locking teeth.
Pull on push plate with hotstick to ensure latch plate is
engaged.
Use hotstick to hook catch strap on push plate slots.
Step 4
Install mating apparatus
Clean and lubricate 200 A interface of mating apparatus
(e.g. insulated protective cap, grounding elbow, M.O.V.E.
arrester).
Bushing adapter cap removal process
Remove mating apparatus from bushing adapter using a
hotstick.
Ensure that catch strap is hooked on push plate.
Grasp latch handle of PUSH-OP bushing using hotstick
and pull backward until bushing adapter is completely
unsealed.
Remove bushing adapter cap by unhooking catch
strap ring with hotstick. Place bushing adapter in clean
protected area.
WARNING
Test for voltage by fuzzing or by using voltage detector.
Do not proceed until bushing is de-energized. Failure to
comply may result in death, severe personal injury or
equipment damage.
3600 A 15, 25, AND 35 KV CLASS PUSH-OP BUSHING ADAPTER CAP INSTALLATION INSTRUCTIONS MN650050EN May 2017
