Table10. Function codes (continued)
Parameter
Unit of
Measure
Security Level
Default Value
Key Entry Limit
To Read To Write To Reset Low High
025 Forward
kW Load Present
XXXX.X kW
kW View NA NA NA NA NA
•This is the present value of the load kW, as a demand value, according to the demand time
interval at FC 46.
026 Forward
kvar Load High
XXXX.X kvar
MM-DD-YYYY HH:MM:SS
kvar View NA Operate Reset* NA NA
•This is the highest value of the load kvar since last reset, as a demand value, according
to the demand time interval at FC 46.
•Date and time of when the highest value occurred is displayed.
026 Forward
kvar Load Low
XXXX kvar
MM-DD-YYYY HH:MM:SS
kvar View NA Operate Reset* NA NA
•This is the lowest value of the load kvar since last reset, as a demand value, according
to the demand time interval at FC 46.
•Date and time of when the lowest value occurred is displayed.
026 Forward kvar
Load Present
XXXX.X kvar
kvar View NA NA NA NA NA
•This is the present value of the load kvar, as a demand value, according to the demand
time interval at FC 46.
027 Maximum Tap
Position
-XX
MM-DD-YYYY HH:MM:SS
Tap View NA Operate Reset* NA NA
•This is the highest tap position that the regulator has reached since last reset.
•The maximum position and associated date and time can be reset using the ENTER key or via
master reset, FC 38. This parameter is not reset by the drag-hand reset switch.
•Date and time of the occurrence of the maximum tap position is displayed.
028 Minimum Tap
Position
-XX
MM-DD-YYYY HH:MM:SS
Tap View NA Operate Reset* NA NA
•This is the lowest tap position that the regulator has reached since last reset.
•The minimum position and associated date and time can be reset using the ENTER key or via
master reset, FC 38. This parameter is not reset by the drag-hand reset switch.
•Date and time of the occurrence of the minimum tap position is displayed.
029 Forward Source
Voltage High
XXX.X Volts
MM-DD-YYYY HH:MM:SS
Volts View NA Operate Reset* NA NA
•This is the maximum source voltage of the regulator since last reset, as a demand value,
according to the demand time interval at FC 46.
•Date and time of the occurrence of the highest source voltage is displayed.
•The control requires source voltage from a differential or source potential transformer or
from the source voltage calculation (see FC 39) to obtain this parameter. Lack of this
voltage will result in the parameter displaying dashes.
