37EATON 620 Mobile Open Circuit Piston Pump Service Manual E-PUPI-TS018-E2 November 2017
Assembly torque values
Instructions
Assembly with longer
segment toward
top of pump
4X Torque
286 ± 29 N.m
Torque
118.5 ± 12 N.m
2X Torque
4± 0.4 N.m
4X Torque
115± 12 N.m
Torque
135 ± 13.5 N.m
Steel side of valve plate
must face End cover
27
26
20
21
24
25
19
3
2
22
1
4
6
7
8
9
5
11
12
13
16
14
15
17
18
29
51
50
52
23
4X Torque
8.2 ± 0.8 N.m
Torque
135 ± 13.5 N.m
Torque
15.5 ± 0.5 N.m
48
29
28
17
18
30
32
49
31
4 X Torque
30 ± 5.4 Nm
Torque
115± 12 Nm
Thru-drive part option
