54
RTK DB5
October 2016
INS DB5 Rev 9
Operating instructions
Tone selection
The required tone should be selected by referring to table 2 below. The 5-way DIL switches on the PCB should then
be set to the code as shown (1 being equivalent to the on position, 0 being equivalent to the off position).
Sound level
The output sound level shown is for a sounder powered from an RTK WIS1211 interface or from an RTK S951 barrier,
fed by 24VDC.
Tone
no
Tone frequency
2
nd
tone
DIL switch
setting 12345
Tone
description
Level dBA
1 Alt Tones 800/970 Hz at ¼ sec 14 11111 88
2 Sweeping 800/970 Hz at 7 Hz 14 11110 91
3 Sweeping 800/970 Hz at 1 Hz 14 11101 94
4 Continuous at 2850 Hz 14 11100 HF 2
nd
tone 102
5 Sweeping 2400-2850 Hz at 7 Hz 4 11011 100
6 Sweeping 2400-2850 Hz at 1 Hz 4 11010 103
7 Slow Whoop 14 11001 94
8 Sweep 1200-500 Hz at 1Hz 14 11000 91
9 All tones 2400-2850 Hz at 2 Hz 4 10111 100
10 Int tone of 970 Hz at 1 Hz 14 10110 83
11 Alt tones 800-970 Hz at 7/8 Hz 14 10101 87
12 Int tone at 2850 Hz at 1 Hz 4 10100 100
13 970 Hz at ¼ sec on 1 sec off 14 10011 83
14 Continuous at 970 Hz 14 10010 LF 2
nd
tone 85
15 554 Hz for 100mS/440 Hz for 400mS 14 10001 French Fire 91
16 Int 660 Hz 150mS on 150mS off 14 10000 Swedish Fire 86
17 Int 660 Hz 1.8 sec on 1.8 sec off 14 01111 Swedish Fire 87
18 Int 660 Hz 6.5 sec on 13 sec off 14 01110 Swedish Fire 88
19 Continuous 660 Hz 14 01101 Swedish Fire 87
20 Alt 554-440 Hz at 1 Hz 14 01100 Swedish Fire 93
21 Int 660 Hz at 7/8 Hz 14 01011 Swedish Fire 88
22 Int 2850 Hz 150mS on 100mS off 14 01010 Pelican Crossing 100
23 Sweep 800-970 Hz at 50Hz 14 01001 Low Freq Buzz 92
24 Sweep 2400-2850 Hz at 50 Hz 14 01000 High Freq Buzz 99
25 3 970 Hz pulses 0.5 on/0.5 off, 1.5 off 14 0 0111 83
26 3 2850 Hz pulses 0.5 on/0.5 off, 1.5 off 14 00110 102
Table 2
