Eaton 9372-FB-P Series - Page 14

INM 9370-RD Rev 5
12
Cover
retaining
screw
Position of
Trunk Surge
module
(optional)
Terminator
module
Slide
protective
cover in this
direction
to remove
Trunk
wiring
terminals
Trunk
cable entry
area
Protective
ground
stud
Enclosure
wall
Figure 4.4 - Trunk Termination Assembly (TTA)



Active
Spare
   

 

Overall
shield
Trunk in
(with Active + Spare cable pairs)






   

 




Figure 4.6 - Active & Spare ‘Trunk In’ cables plus
‘Trunk Out’ cable
Figure 4.5 - ‘Trunk In’ with Active & Spare cable
pairs
