P-164000427 SMALL and LARGE BATTERY CABINET 9
Revision 2 User's and Installation Guide
3.
Carefully slide the battery cabinet off the pallet. Now the battery cabinet is ready to
be placed aside the UPS.
Notes of installation location with
93PM UPS
:
Both sides can be used for battery cabinet placement but for easier service
access to UPS, on the 93PM 30-150 kW UPS right side is preferred, and on
the 93PM 160-200 kW left side is preferred.
The battery cabinet must be located on the right side of 93PM 30-50 kW UPS
cabinet if wiring through cabinet side panels. The 93PM 160-200 kW UPS
does not enable wiring through its side panel.
Notes of installation location with
93E UPS
:
Both sides can be used for battery cabinet placement with the 93E UPS but on
the left side is preferred with the 80-120 kVA UPS, and on the right side is
preferred with the 160-200 kVA UPS to more easily access the battery input
terminals through the bottom or the rear entry.
4.
Open the battery cabinet and locate the external power wiring shipped along the
cabinet.
5.
Cables with single insulation are provided with the battery cabinet. These cables
can be used for internal wiring, i.e. when the UPS cabinet and the battery cabinet
are mounted side by side with no gap in between, and cables are routed directly
from cabinet to cabinet. If any length of the cables is routed outside the cabinets
then they need to be replaced by double insulated cables or a supplementary
insulation needs to be used with cables provided.
6.
Apply cable glands and/or plastic pass-through collars accordingly.
WARNING
Make sure all power sources are disconnected before next steps.
7.
Connect the power cables and signal wires to the UPS. No signal wires are
connected to 93E UPS.
8.
If multiple
cabinets
are to be
used, repeat
the
steps
to the rest of the
cabinets
and
be sure
to
daisy chain the signal wire
harnesses
in the next
cabinet. Signal wires are
daisy chained by cutting the multiple connector and extra length of the cables and
connecting them to TB2 terminals 5-8. Look at the Figure 2-6.
