Figure 5. Connecting leads to terminal board.
Lead
Tool
Cable
Entrance
Ground
Point
Universal
Control Box
Mounting
Bracket
Figure 3. CRA external side view.
Figure 4. Tool supplied for connecting leads.
4 CL-7 control replacement assembly installation instructions and service information MN225017EN October 2016
