Page 2 I.L. 17562
PR 0.3 Effective 8/99
TABLE OF CONTENTS
Section 1 - Introduction ……………………………………………………………... 3
Section 2 - Product Overview ……………………………………………………….. 7
Section 3 - Specifications …………………………………………………………….. 11
Section 4 - Operator Panel …………………………………………………………… 14
Section 5 - Programming the MP-3000 ……………………………………………… 45
Section 6 - Installation and Wiring …………………………………………………. 66
Section 7 - Startup …………………………………………………………………….. 80
Section 8 - Motor Thermal Protection Basics …………………………………….. 84
Section 9 - Application and Settings ………………………………………………. 89
Section 10 - Data Communications ………………………………………………….. 105
Section 11 - Testing …………………………………………………………………… 109
Section 12 - Troubleshooting ………………………………………………………… 111
