35
Column A - Analog Output
Block Parameter Range
A1 Assignment 0 Rate
1 Six digit total
2 Batch
3 Cycle
A2 Offset Value 000000-999999
A3 Full Scale Value 000000-999999
The 4-20 mA and 0-10 V analog outputs can be assigned to follow the ratemeter, the
totalizer (six digit mode), the cycle counter, or the batch counter. Obviously, the cycle
counter and batch counter options are only available in the batch control. The offset
value entered in block A2 is the displayed value that causes the analog output to go
to its minimum output of 4 mA and 0 V. The full scale value entered in block A3 is the
displayed value that causes the analog output to go to its maximum output of 20 mA
and 10 V. If a decimal point is programmed for the assigned rate or count display, the
decimal point will appear in its proper position in blocks A2 and A3.
PROGRAMMING cont.
