Eaton EASY Series User Manual

2/12 Emergency On Call Service: Local representative (Eaton.eu/aftersales) or +49 (0) 180 5 223822 (de, en)
02/18 IL05013015Z
Standard connection, inputs
Standardanschluss, Eingänge
Raccordement standard, entrées
Conexión estándar, entradas
Collegamento standard, ingressi
Стандартное подключение, вводы
en
de
fr
es
it
ru
L
N
> 1 A
NL N
l1
I2
I3
I4 I5
I6
I7 I8
AC: U
e
= 115/230 V h 50/60 Hz (85 – 264 V h)
I
e
= 40 mA 115 V ~, 20 mA 230 V ~
AB: U
e
= 24 V h 50/60 Hz (20.4 – 28.8 V h)
I
e
= 200 mA 24 V ~
0.5 – 0.7 Nm
3.5 mm
I1–I6 = 4 mA 24 V
I7, I8 = 2 mA 24 V
1 f 14 V AC
0 F 6 V
AB
I1–I6 = 0.5 mA 230 V
I1–I6 = 0.25 mA 115 V
I7, I8 = 6 mA 230 V
I7, I8 = 4 mA 115 V
1 f 79 V
0 F 40 V
AC
1 f 9.5 V DC
1 f 7 V AC
+10 V
10 V
5 V
0 V
h
0
512 1023
0 V
AB
I7, I8
EASY5…-AB-…C…
EASY5…-AC-…C…
6,5 mm (0.25”)
6,5 mm (0.25”)
0.2- 2.5 mm²
AWG 22-12
0.2- 4 mm²
AWG 22-12
+10 V
0 V
10 V
5 V
0 V
+... V
h
0
512 1023
0 V
DC: +24 V
DA: +12 V
0 V
l7, l8
> 1 A
0 V
l1
I2
I3
I4 I5
I6
I7 I8
1 f 15 V
0 F 5 V
DC
I1-I6 = 3.3 mA/24 V
I7, I8 = 2.2 mA/24 V
1 f 8 V
0 F 4 V
I = 3.3 mA/12 V
I7, I8 = 1.1 mA/12 V
DA
0.5 – 0.7 Nm
3.5 mm
DA: U
e
= 12 V H (10.2 – 14.4 V H) I
e
= 140 mA
DC: U
e
= 24 V H (20.4 – 28.8 V H) I
e
= 80 mA
1 f 8 V
EASY5…-DA-…C…
EASY5…-DC-…C…
6,5 mm (0.25”)
6,5 mm (0.25”)
0.2- 2.5 mm²
AWG 22-12
0.2- 4 mm²
AWG 22-12

Eaton EASY Series Specifications

General

Manufacturer	Eaton
Series	EASY Series
Mechanical Life	10, 000, 000 operations
Operating Temperature	-25°C to +55°C
Category	Relays
Output Type	Relay, Transistor
Programming	Software
Display	LCD display (on some models)
Expansion Modules	Yes
Communication	RS-485, Modbus
Rated Current	Up to 10A (relay outputs)
Rated Voltage	250V AC
Electrical Life	100, 000 operations at rated load
Mounting Type	DIN rail mount
Supply Voltage	12-24V DC, 24V AC/DC, 100-240V AC/DC
Analog Outputs	1-2 (depending on model)
