Eaton EASY512-AB-RCX User Manual

4/12 Emergency On Call Service: Local representative (Eaton.eu/aftersales) or +49 (0) 180 5 223822 (de, en)
02/18 IL05013015Z
EASY6…-AC-…E
EASY6…-DC-…E
L
N
> 1 A
R10R9R8R7R6R5R4R3R2R1E+ E–
R11
R12 NNL
Input 115/230 V 115/230 V
R1–R12 = 0.5 mA 230 V
0.25 mA 115 V
1 f 79 V
0 F 40 V
264 V
U
e
= 115/230 V h
50/60 Hz
(85 – 264 V h)
I
e
= 70 mA 115 V
35 mA 230 V
0.5 – 0.7 Nm
(4.4 – 6.2 lb-in)
0.6 x 3.5 mm
(0.02 x 0.14
")
6,5 mm (0.25”)
6,5 mm (0.25”)
0.2- 2.5 mm²
AWG 22-12
0.2- 4 mm²
AWG 22-12
U
e
= 24 V H
(20.4 – 28.8 V H)
I
e
= 140 mA
+24 V
0V
> 1 A
1 f 15 V
0 F 5 V
R10R9R8R7R6R5R4R3R2R1E+ E–
R11
R12 0V0V+24V
28.8 V
R1–R12 = 3.3 mA; 24 V
Input 24 V 24 V
0.5 – 0.7 Nm
(4.4 – 6.2 lb-in)
0.6 x 3.5 mm
(0.02 x 0.14
")
6,5 mm (0.25”)
6,5 mm (0.25”)
0.2- 2.5 mm²
AWG 22-12
0.2- 4 mm²
AWG 22-12

Eaton EASY512-AB-RCX Specifications

General

Brand	Eaton
Model	EASY512-AB-RCX
Category	Relays
Language	English
