Eaton EASY512-AB-RCX User Manual

6/12 Emergency On Call Service: Local representative (Eaton.eu/aftersales) or +49 (0) 180 5 223822 (de, en)
02/18 IL05013015Z
Transistor outputs – Transistor-Ausgänge – Sorties à transistors – Salidas de transistor – Uscite a transistor –
Выводы транзистора
EASY5…-DC-TC…, EASY410-DC-TE
EASY7…-DC-TC…, EASY6…-DC-TE
EASY202-RE
25 000
RL
24 V H
8A
115 V h 8A
230 V h 8 A
3A
3A
3A
1000 W
10 x 58 W
+ 24 V
H
0 V H, N
F
8 A/B 16
L1, L2, L3 (115/230 Vh)
12 2
1
10 000 000
S2
S1
0 V H
R
L
+... V
0 V Q1 Q2 Q3 Q4
S1 S2 S3 S4
5 W/24 V H
Q
Q
24 V H 0.5 A0.5 A
+24 V H
f 2.5 A
20.4 – 28.8 V H
6,5 mm (0.25”)
6,5 mm (0.25”)
0.2- 2.5 mm²
AWG 22-12
0.2- 4 mm²
AWG 22-12
0 V
Q1
S1 S2 S3 S4 S5 S6 S7 S8
Q2 Q3 Q4 Q5 Q6 Q7 Q8
F 10 A
Q
24 V
Q
0 V
Q
24 V
Q
F 10 A
f 2.5 A
f 2.5 A
0 V H
24 V H
EASY7…-DC-TC(X)
EASY6…-DC-TE
EASY6…-DC-TE
EASY7…-DC-TC(X)
(20.4 – 28.8 V H)
+ 24 V H
RL
5 W/24 V
0.5 A
24 V H
0.5 A
6,5 mm (0.25”)
6,5 mm (0.25”)
0.2- 2.5 mm²
AWG 22-12
0.2- 4 mm²
AWG 22-12
