Eaton EASY512-AC-R - Standard Connection and Outputs; Relay Outputs for EASY5 and EASY410; Relay Outputs for EASY7 and EASY6

Emergency On Call Service: Local representative (Eaton.eu/aftersales) or +49 (0) 180 5 223822 (de, en) 5/12
02/18 IL05013015Z
EASY410-DC-…
Relay outputs – Relais-Ausgänge – Sorties à relais – Salidas con relé – Uscite a relè – Выводы реле
EASY5…-…-R…, EASY410-DC-RE
EASY7…-…-RC, EASY6…-…-RE
Standard connection, outputs
Standardanschluss, Ausgänge
Raccordement standard, sorties
Conexión estándar, salidas
Collegamento standard, uscite
Стандартное подключение, выводы
0.5 – 0.7 Nm
(4.4 – 6.2 lb-in)
U
e
= 24 V H
(20.4 – 28.8 V H)
I
e
= 70 mA
+24 V
0V
> 0.5 A
1 f 15 V
0 F 5 V
0V+24VR6R5R4R3R2R1E+ E–
0V
28.8 V
R1–R6 = 3.3 mA; 24 V
Input 24 V 24 V
0.6 x 3.5 mm
(0.02 x 0.14
")
6,5 mm (0.25”)
6,5 mm (0.25”)
0.2- 2.5 mm²
AWG 22-12
0.2- 4 mm²
AWG 22-12
en
de
fr
es
it
ru
0 V H, N
F 8 A/B 16
L1, L2, L3 (115/230 V h)
+ 24 V H
25 000
R
L
24 V H 8 A
115 V h 8 A
230 V h 8 A
3 A
3 A
3 A
1000 W
10 x 58 W
1
2
1
2
1
2
1
2
10 000 000
Q1
S1
Q2
S2
Q3
S3
Q4
S4
6,5 mm (0.25”)
6,5 mm (0.25”)
0.2- 2.5 mm²
AWG 22-12
0.2- 4 mm²
AWG 22-12
10 000 000
0 V H, N
L1, L2, L3 (115/250 V h)
+24 V H
Q1
12
S1
F 8 A/B 16
Q2
12
S2
Q3
12
S3
M
Q4
12
S4
Q5
12
S5
Q6
12
S6
EASY7…-…-RC
EASY6…-…-RE
