Eaton ECIO-DN - Dimensions (Ecio-Dn, Ecio-120-Dn)

To Next Page

To Previous Page

11/06

DIMENSIONS (ECIO-DN, ECIO-120-DN)

All dimensions are in inches

2.999

2.300

4.760

2.628

3.006

1.000

.535

3.500

.297

.420

3.750

.635.700

.350

.830

DEPLUGGABLE

TERMINAL BLOCKS

IND. CONT. EQ.

LISTED

784X

REMOTE

RESET

DEVICENET MODULE/NETWORK S

OVERLOAD COMM. S TAT US

TAT US

R 1 2 3 4 5R V + I1 I2 I3 I4

DeviceNet Communication and I/OECIO-DN

PILO T DUT Y R ATIN G

480VA @ 240VAC, B30 0

5A @ 240 VAC

GENERA L PURPOS E

SCREW TORQUE RATING 0.5 Nm (5 in-lbs. )

DIGI TAL

INPUTS

OUTPU T A OUTPU T B
