ECIO- DN, ECIO-120-DN, ECOM-DN SPECIFICATIONS
Output Relay Contact Rating – SPDT (1), SPST (1) (CIO-DN or CIO-120-DN)
Pilot Duty 480VA @ 240VAC, B300
General Purpose 5A @ 240VAC
Inputs (4) – general purpose (CIO-DN,CIO-120-DN Only)
Voltage Range
12–24VDC (module powered, V+ ECIO-DN only)
90–130VAC, 50/60Hz (ECIO-120-DN only)
Current 2mA (typical)
Normally open pushbutton
rated 24VDC, 10mA (min.)
Power Requirements
Voltage 12–24VDC
Current
60mA (max.) ECIO-DN or ECIO-120-DN
40mA (continuous) ECOM-DN
Power 1.5 Watts (max.)
Weight
14 oz. (ECIO-DN or ECIO-120-DN)
1.6 oz. (ECOM-DN)
Enclosure
Polycarbonate
Terminal (depluggable terminal block)
Torque 3 in.-lbs. (max.)
Wire AWG 12–20 AWG
Safety Marks
UL UL508 (File #E68520)
CSA C 22.2
Standards Passed
Electrostatic Discharge (ESD) IEC 1000-4-2, Level 3, 6kV contact, 8kV air
Radio Frequency Immunity, Radiated 159 MHz, 10V/m
Fast Transient Burst IEC 1000-4-4, Level 3, 4 kV input power
Hi-Potential Test Meets UL508 (2 x rated V +1000V for 1 minute)
Environmental
Temperature Range
Ambient Operating: -20° to 70°C (-4° to 158°F)
Ambient Storage: -40° to 80°C (-40° to 176°F)
Class of Protection IP20, NEMA 1 (Finger Safe)
Relative Humidity 10-95%, non-condensing per IEC 68-2-3
ODVA Approved
