5INSTALLATION AND OPERATION MANUAL 25-17603-C March 2023 www.eaton.com
2. About the EF-CBD130
2.2. Technical Specifications
Part Number EF-CBD130
Standard
Listed LPCB Certification
Compliance EN 54-12:2015
Fire Detection and Alarm Systems BS 5839 Part 1:2017
Specification
Operating Voltage 20 V to 28 V DC
Current Parameters Standby: 23mA Commission: 56mA Alarm: 33mA
Beam Sensor Sensitivity [via Encoder] Level 1: 2.6 dB High Sensitivity
Level 2: 3.8 dB Medium Sensitivity
Level 3: 5.8 dB Low Sensitivity
Beam Pathway Length [via Encoder] Span 1: 8 to 20 meters Limited Path
Span 2: 20 to 40 meters Short Path
Span 3: 40 to 70 meters Normal Path
Span 4: 70 to 100 meters Long Path
Beam Path Angle ±0.4º Directional (This data takes the average of the left and right
deflection angles.)
Alignment Guide Laser Beam Pointer
Digital Display Guide Nixie Tube
LED Indicator Guide Red: Fire ; Yellow: Fault ; Green: Alignment
Reset Time Less than 2 Second
Relay Capacity [Fire & Fault] Normally Open & Close/ 2.0 A; 30 VDC
Physical
Material / Colour ABS / White
Dimension / Weight L:190.87 x W:126.87 x H:91.96 mm / 440 gm
Weight 0.130 Kg with base
Environmental
Operating Temperature -10°C to +50°C
Ingress Protection Rating IP30 [IP66 glue seal-For permanent fixing, Not EN54-12 approved]
Humidity 0 to 95% Relative Humidity, Non condensing
