Figure 12. Inside drive frame.
Motor
Brake Assembly
Raise Safety
Switch
Neutral Switch
Lower Safety
Switch
Reversing
Segment
Actuator
Drive Sprocket
Gear
Logic Switches
Chain
7
QD5 QUIK-DRIVE TAP-CHANGER INSTALLATION AND MAINTENANCE INSTRUCTIONS MN225012EN March 2016
