Eaton FS-4205B - Table of Contents

TABLE OF CONTENTS
FOREWORD ................................................................ 2
MODEL DESIGNATIONS AND SPECIFICATIONS .................................. 3
LUBRICATION ............................................................... 4
OPERATION ................................................................ 6
POWER FLOW ............................................................... 7
TORQUE RECOMMENDATIONS ................................................ 8
PREVENTIVE MAINTENANCE ................................................. 10
PRECAUTIONS
DISASSEMBLY ............................................................ 12
INSPECTION .............................................................. 12
REASSEMBLY ............................................................. 14
DISASSEMBLY AND REASSEMBLY - SHIFTING CONTROLS
GEARSHIFT LEVER HOUSING ASSEMBLY ....................................... 15
SHIFT BAR HOUSING ASSEMBLY .............................................. 18
REMOVAL - YOKE AND CLUTCH HOUSING ..................................... 27
DISASSEMBLY -TRANSMISSION .............................................. 29
REASSEMBLY - TRANSMISSION .............................................. 43
INSTALLATION- CLUTCH HOUSING ........................................... 57
INSTALLATION - SHIFTING CONTROLS ........................................ 58
OPTIONS .................................................................. 59
