Installation procedure
CBC-8000 capacitor bank control installation and operation instructions MN916001EN—October 2018 Eaton.com 21
3. To install the control into a meter socket, follow the
procedure
Socket mount installation on Page 25. To
install the control on a utility pole, follow the procedure
Pole mount installation on Page 26.
Note: Pole mount applications do not use a meter socket.
Table 5. Mounting options.
Mounting Style Jaw 1 Jaw 2 Jaw 3 Jaw 4 Jaw 5 Jaw 6
Option 1
Line Neutral Trip Close
Option 2
Line Neutral Close Trip
Option 3
SL
a
Neutral Line Trip
SH
a
Close
Option 4
Line Neutral
SL
a
SH
a
Trip Close
Option 5
Line Neutral
NSL
a
NSH
a
Trip Close
Option 6
Line Neutral
NSH
a
NSL
a
Trip Close
Option 7
Line Neutral
NSH
a
CSH
a
Trip Close
Option 8
Pole mount with standard male 7-pin DIN connector.
Option 9
Pole mount with standard male 14-pin DIN connector.
Option 0
Pole mount with standard male 5-pin DIN connector.
Option A
Custom socket mount – contact Eaton’s Cooper Power series for more information.
Option B
Custom pole mount – contact Eaton’s Cooper Power series for more information.
a. SH is Line Current/Voltage Signal High, SL is Line Current/Voltage Signal Low, NSH is Neutral Current Signal High, NSL is Neutral Current
Signal Low, and CSH is Line Current Signal High. Refer to
Figure 27 and Figure 28 for a diagram that shows how the jaws are numbered for
the four-jaw and six-jaw meter socket configurations. Note: The sensor inputs are rated for 0 to 10 VAC.
