17IZM32 / IN32 low voltage air circuit breaker MN013017EN May 2022 www.eaton.com
Section 3: Circuit breaker description and operation
Figure 3-4 Typical standard drawout circuit breaker front cover
5
6
2
1
4
3
11
8
7
10
13
14
12
9
Trip flag (pop-out indicator)
Three accessory windows
Trip unit
Contact status (open-close)
Spring status (charged-discharged)
Manual OFF button (push)
Manual ON button (push)
Manual charge handle
Optional operation counter
Padlockable levering device access door for drawout breaker
Color-coded breaker position indicator
Nameplate
Trip unit test port
Trip unit cover. Plastic cover is provided which allows the
settings to be viewed but not changed.
2
3
14
13
4
5
6
7
9
10
8
1
2
3
14
13
4
5
6
7
9
10
11
8
1212
