Eaton M-Max series Operating Instructions

04/10 MN04020001Z-EN
9
1M-Max
TM
Series
System overview
Figure 3: System overview
a Frequency inverters MMX-…
b Mounting frame (for fieldbus connection) MMX-NET-XA
c Fieldbus connection
CANopen XMX-NET-CO-A
PROFIBUS DP with XMX-NET-PS-A screw terminals
PROFIBUS DP with XMX-NET-PD-A Sub-Dm connector
DeviceNet XMX-NET-DN-A
d DEX-LN… mains reactor, DEX-LM3… motor reactor, SFB400… sinusoidal filter
e BR… braking resistor
f Communication module MMX-COM-PC
I
OK
BACK
RESET
LOC
REM
COMM
AC DRIVE
ERROR
a
d
e
f
b
c
