Eaton Magnum DS User Manual

7
Instruction Booklet IB01900002E
Effective June 2011
Instructions for Magnum DS Metal-Enclosed
Low-Voltage NEMA 3R Assemblies
EATON CORPORATION www.eaton.com
C
C
9255C35
120.0
[3047]
OVERALL DEPTH
18.4
[468]
BUS OPENING
(FROM BASE)
109.1
[2772]
105.1
[2668]
51.2
[1301]
2.0
[51]
4.0
[102]
3.9
[99]
2.3
[58]
28.6
[726]
(FROM
BASE)
26.0
[660]
43.4
[1102]
AISLE WIDTH
117.1
[2974]
(BASE)
30.2
[767]
(OPENING
WIDTH)
0.6
[15]
33.5
[850]
(DOOR
WIDTH)
5.8
[146]
5.8
[146]
111.5
[2832]
OVERALL
HEIGHT
Figure 3. Side Elevation NEMA 3R Assembly Rear-Accessible with Walk-in Aisle Way.

Eaton Magnum DS Specifications

General

Rated Voltage	600V AC
Standards	UL 489, CSA C22.2 No. 5, IEC 60947-2
Voltage Rating	600 V AC
Interrupting Capacity	Up to 200kA
Voltage	600V AC
Poles	3
Interrupting Rating	Up to 200kA
Mounting	Fixed
