Eaton Magnum DS User Manual

8
Instruction Booklet IB01900002E
Effective June 2011
Instructions for Magnum DS Metal-Enclosed
Low-Voltage NEMA 3R Assemblies
EATON CORPORATION www.eaton.com
Figure 4. Side Elevation NEMA 3R Assembly Rear-Accessible without Walk-in Aisle Way.
C
C
9259C06
86.0
[2185]
(BASE)
26.0
[660]
28.6
[726]
(FROM
BASE)
51.2
[1301]
2.0
[51]
4.0
[102]
109.8
[2789]
OVERALL
HEIGHT
105.1
[2669]
109.1
[2770]
4.2
[107]
18.4
[468]
88.0
[2236]
OVERALL DEPTH
BUS OPENING
(FROM BASE)

Eaton Magnum DS Specifications

General

Rated Voltage	600V AC
Standards	UL 489, CSA C22.2 No. 5, IEC 60947-2
Voltage Rating	600 V AC
Interrupting Capacity	Up to 200kA
Voltage	600V AC
Poles	3
Interrupting Rating	Up to 200kA
Mounting	Fixed
