STEP 4 (Continued)
Parameters — M1
Basic Parameters — M1

Parameter value can only be changed when the SVX9000 is stopped.
Code Parameter Min. Max. Unit Default Cust ID Note
P1.1 Min frequency 0.00 P1.2 Hz 0.00 101
P1.2 Max frequency P1.1 320.00 Hz 60.00 102 NOTE: If f
Max
> motor
synchronous speed,
check suitability for
motor and drive system
P1.3 Acceleration time
1
0.1 3000.0 s 3.0 103
P1.4 Deceleration time
1
0.1 3000.0 s 3.0 104
P1.5 Current limit 0.4 x
I
H
2 x I
H
AI
L
107 I
H
is the nominal current
rating of the SVX9000
P1.6

Nominal voltage
of the motor
180 690 V HVX-2:
230V
HVX-4:
460V
110 Motor nameplate value
P1.7

Nominal
frequency of the
motor
30.00 320.00 Hz 60.00 111 Motor nameplate value
P1.8

Nominal speed of
the motor
300 20 000 rpm 1775 112 Motor nameplate value
— The default applies
for a 4-pole motor and a
nominal size SVX9000.
P1.9

Nominal current
of the motor
0.4 x
I
H
2 x I
H
AI
H
113 Motor nameplate value
P1.10

Power factor 0.30 1.00 0.85 120 Motor nameplate value
P1.11 Start function 0 1 0 505 0 = Ramp
1 = Flying start
P1.12 Stop function 0 3 1 506 0 = Coasting
1 = Ramp
2 = Ramp+Run enable
coast
3 = Coast+Run enable
ramp
P1.13 Local Control
Place
13 2 171 1 = I/O Terminal
2 = Keypad
3 = Fieldbus
P1.14 Remote Control
Place
13 1 172 1 = I/O Terminal
2 = Keypad
3 = Fieldbus
P1.15 Remote reference 0 3 0 174 0 = AI1
1 = AI2
2 = Keypad
3 = Fieldbus
P1.16

V/Hz optimization 0 1 0 109 0 = Not used
1 = Automatic torque
boost
P1.17 Current reference
offset
01 1 302 0 = No offset, 0 – 20 mA
1 = Offset, 4 mA – 20 mA
P1.18 Analog output
function
08 1 307 0 = Not used
1 = Output freq. (0 – f
Max
)
2 = Freq. reference
(0 – f
Max
)
3 = Motor speed
(0 – Motor nominal
speed)
4 = Output current
(0 – I
nMotor
)
5 = Motor torque
(0 – T
nMotor
)
6 = Motor power
(0 – P
nMotor
)
7 = Motor voltage
(0 – U
nMotor
)
8 = DC-bus volt
(0 – 1000V)
P1.19

DIN3 function 0 6 1 301 0 = Not used
1 = Ext. fault, closing
cont.
2 = Ext. fault, opening
cont.
3 = Run enable, cc
4 = Run enable, oc
5 = Force cp. to Local
6 = Force cp. to Remote
P1.20 Preset speed 1 0.00 P1.2 Hz 0.00 105 Speeds preset by
operator
P1.21 Preset speed 2 0.00 P1.2 Hz 60.00 106 Speeds preset by
operator
P1.22 Automatic restart 0 1 0 731 0 = Disabled
1 = Enabled
