PXM 2000 Quick Start Guide
Mechanical Installation
IM02601002E www.eaton.com 1
Mechanical Installation
4” Diameter round mounting
92 mm Square Form
ANSI Studs
4” Round Form
Caution: Do not overtighten
nuts as this can damage the me-
ter. The maximum installation
torque is 0.4 Newton-Meter.
92 mm square form
Unscrew ANSI studs for
DIN Installation
