PXM 2000 Quick Start Guide
Network Planning
4 www.eaton.com IM02601002E
Network Planning
The hardware for the Power Xpert Meter 2000 family is similar to other EATON IQ 250
and 260 meters except that these meters include an integrated, multi-function Ethernet
network gateway card. The Power Xpert Meter 2000 Gateway Card provides many of
the features found in the rest of the Power Xpert line of meters, including:
• Local web server
• Modbus/TCP communitations
• SNMP communications
• Power Xpert Software (PXS) communications
• BACnet/IP communications
The Network PC requires a web browser (Internet Explorer versions 7 or 8 are sup-
ported) and an installed version 6 or later of the JAVA J2SE JRE (Java Runtime Environ-
ment). If Java is not already installed, you or the network administrator may download
it from www.java.com and install it per Sun’s instructions. See the Power Expert Meter
2000 User and Installation Guide for additional information.
An Ethernet connection is used for configuring the meter’s gateway card communica-
tion settings via a web browser. You may need to contact your network administrator for
some network and configuration information. In preparation, you will need to decide if
the meter will be manually assigned a fixed (static) IP address or will be automatically
assigned a fixed IP address by a DHCP server somewhere on the network. With either
method the assigned network address must not change once the meter has been de-
ployed. Changing the IP address will cause loss of communication until the associated
client PCs change the corresponding meter’s IP addresses.
Discuss with your network administrator whether you should manually configure the
meter with an assigned IP address or whether the DHCP server will assign one. For
the DHCP server to provide a fixed IP address, your network administrator will need to
know the MAC address assigned to the meter.
H
Caution
Eaton strongly recommends using a fixed IP address if an Eaton PXS system will be ac-
cessing the meter. Otherwise, should the IP address change (after a power outage, for
example), PXS will no longer be able to access data from the meter.
The MAC address is found on a small label that consists of 14 letters and numbers. It
looks something like:
002080850047EF
Locate the MAC address on your meter and record it here.
MAC Address: ______________________________________________________________
Is DHCP going to be used to assign the IP address to your meter? ___ Yes ___ No
If Yes:
Provide the MAC address to the network administrator and record the fixed IP address
the network administrator will assign to your meter in the DHCP server here:
IP Address:
__________________________________________________________________
