Maintenance
6.0
6.1 Filter Service
1
2
3
Unclasp the retaining clips and hinge
the front panel down.
Note
The front panel is secured to the unit
using lift off hinges. If access is limited,
slide the front panel to the right
and it will lift away. Store away during
the service.
Remove both the supply and
extract filter by gentry pulling on
the tabs of each filter.
Gently clean by tapping or using a
vacuum cleaner.
Reassemble the filters back into the
unit. Take note of the air flow direction
printed on each filter.
25
POWER OFF THE POWER SUPPLY PRIOR TO OPENING OR
REMOVING THE FRONT PANEL FOR SERVICE/ MAINTENANCE
