3
500mm
900mm
500mm
Unit Installation
2.0
2.1 Service Void
Before installation, we advise installers to fix all mains and touchscreen wiring along with any internal
accessories prior to fixing the MVHR unit in position, leaving approximately 500mm tails to allow for
internal wiring. See section 2.7.1 for wiring details
Installation should be carried out by a suitable qualified and competent person.
If the unit is wall mounted, the wall should have sufficient strength to support the unit. The unit may
also be floor mounted.
Do not use this MVHR unit as a support for any other equipment.
