Operating instructions
8300100096
VBS0560CTTPS
Translation of the original operating instructions
All dimensions in mm.
Inlet ring 8217102237 with pressure tap (k-factor: 381)
Item no. 1170000592 · ENU · Change 230626 · Approved 2022-11-09 · Page 5 / 17
